Description
Product Description
| DLX24RP-G | ||
| Power Supply | V-Ph-Hz | 230 – 1 – 50 |
| Rating Cooling Capacity | W | 7331 (3049 – 8445) |
| Rating Cooling Capacity | BTU/h | 2500 (10400 – 28800) |
| Cooling Power Input | W | 2260 (230 – 3010) |
| EER | 3,24 | |
| SEER | 6,4 | |
| Cooling Energy Efficiency Class | A++ | |
| Rated Heating Capacity | W | 7624 (2082 – 9442) |
| Rated Heating Capacity | BTU/h | 26000 (7100 – 32200) |
| Heating Power Input | W | 2060 (330 – 3150) |
| COP | 3,71 | |
| SCOP Warmer | 5,1 | |
| Heating Energy Efficiency Class Warmer | A+++ | |
| Max. Input Consumption | W | 3600 |
| Cooling Current | A | 9,8 (1,0 – 13,1) |
| Heating Current | A | 9,2 (1,4 – 13,7) |
| Max. Current | A | 16 |
| Indoor Sound Pressure Level (Hi/Mi/Lo) | dB(A) | 46/44/35/27 |
| Indoor Sound Power Level | dB(A) | 59,0 |
| Outdoor Sound Pressure Level | dB(A) | 59,0 |
| Outdoor Sound Power Level | dB(A) | 65,0 |
| Indoor Air Flow (Hi/Mi/Lo) | m³/h | 1050/970/650 |
| Dimensions Indoor Unit (WxDxH) | mm | 1106x232x342 |
| Dimensions Outdoor Unit (WxDxH) | mm | 845x363x702 |
| Indoor Unit Net/Gross Weight | kg | 14,3/18,2 |
| Outdoor Unit Net/Gross Weight | kg | 50/53,1 |
| Refrigerant Type – GWP | R32 – 675 | |
| Refrigenrant Charged Quantity | kg | 1,6 |
| Refrigerant Piping (Liquid Side/Gas Side) | in | (3/8 – 5/8) |
| Refrigerant Piping Length (Max) | m | 50 |
| Max Difference Level Between Indoor and Outdoor Unit | m | 25 |
| Compressor Type | ROTARY | |
